Tools

These are some common tools used to work on this device. You might not need every tool for every procedure.

Identification

You can find the badge on the front of the camera that has "EOS Rebel T5i" (or "EOS 700D"). Alternatively, you can check the label on the bottom of the camera for the SKU "DS126431".

Technical Specifications

General:

  • Type: Digital, single-lens reflex, AF/AE camera with built-in flash
  • Recording Media: SD, SDHC, and SDXC memory cards (compatible with UHS-I)
  • Lens Mount Type: Canon EF mount
  • Shutter Speeds: 1/4000 sec to 30 sec, Bulb, X-sync at 1/200 sec
  • Interface:
    • Audio/video out/digital terminal
    • HDMI mini out terminal
    • External microphone in terminal
    • Remote control terminal
  • ISO Speed: 100-12800 (extends to 25600)

Image Sensor:

  • Type: CMOS sensor
  • Effective Pixels: 18.00 megapixels
  • Aspect Ratio: 3:2
  • Image Sensor Size: 22.3 x 14.9 mm

Drive System:

  • Modes: Single shooting, continuous shooting, and self-timer with 2-10 sec delays
  • Continuous Shooting Speed: Max. 5 shots/sec
  • Maximum Burst:
    • JPEG (Large/Fine): 22-30 shots
    • RAW: 6 shots
    • RAW + JPEG (Large/Fine): 3 shots

Movie Shooting:

  • Recording Format: MOV
  • Audio: Linear PCM
  • Recording Size and Frame Rate:
    • 1920 x 1080 (Full HD): 30p / 25p / 24p
    • 1280 x 720 (HD): 60p / 50p
    • 640 x 480 (SD): 30p / 25p

LCD Monitor:

  • Type: TFT color liquid-crystal monitor
  • Size: 7.7 cm (3.0 in)
  • Aspect Ratio: 3:2
  • Touch Screen Technology: Capacitive sensing

Physical:

  • Dimensions:
    • Width: 133.1 mm (5.2 in)
    • Height: 99.8 mm (3.9 in)
    • Depth: 78.8 mm (3.1 in)
  • Weight (body only): 525 g (18.5 oz)

Source: Canon Camera Museum Webpage
